sv-1900-ds
数字标牌与多媒体终端专用, intel celeron j1900处理器, 1*vga, 1*hdmi, 1*edp, 2*mini-pcie
- 数字标牌与多媒体终端专用主板
- 采用intel bay trail celeron j1900处理器
- 6*usb, 2*com, 1*千兆网口
- 1*vga, 1*hdmi, 1*edp, 支持多种双屏异显
- 2*mini-pcie支持msata和wifi/3g/4g
- dc 12v供电
规格
|
general |
|
|
cpu |
intel® celeron® j1900 cpu, quad-core, up to 2.42 ghz, tdp 10w |
|
memory |
ddr3l-1333, 2*so-dimm, up to 16 gb |
|
storage |
1*sata 2.0, 1*msata |
|
expansion interface |
2*mini-pcie (1*msata, 1*wifi/3g/4g supported) |
|
bios |
ami uefi bios |
|
system |
windows 7/8.1/10, linux |
|
i/o interface |
|
|
ethernet |
1*realtek® 1gbps pcie ethernet controller, rj45 |
|
serial |
2*rs232 |
|
usb |
1*usb 3.0, 5*usb 2.0 |
|
audio |
realtek® 5.1 channel hda codec, with mic/line-out |
|
display |
|
|
display interface |
1*vga: max resolution up to 2560*1600@60hz 1*hdmi: max resolution up to 1920*1200@60hz 1*edp: max resolution up to 1920*1200@60hz |
|
multiple display |
dual |
|
mechanical & environment |
|
|
dimension |
185*110mm |
|
power input |
dc 12v |
| temperature |
operation: 0℃~60℃, storage: -25℃~75℃ |
|
relative humidity |
operation: 10%~90%, storage: 5%~95%, non-condensing |
