sv4-h3134
intel coffee lake 8代core i3/i5/i7处理器, h310芯片, 3*pcie, 4*pci, 6*com, 9*usb, 2*lan
- 支持intel coffee lake 8代core i3/i5/i7处理器
- 采用intel h310芯片组
- 6*com, 9*usb, 2*intel千兆网口
- 1*vga, 1*hdmi, 1*dvi, 1*edp, 支持双屏异显
- 1*pcie x16, 1*pcie x4, 1*pcie x1, 4*pci
- 2*mini-pcie支持msata和wifi/3g/4g
规格
|
general |
|
|
cpu |
intel® 8th generation coretm i3/i5/i7, pentium®, celeron® cpu, lga1151 |
|
chipset |
intel® h310 chipset, tdp 6w |
|
memory |
ddr4-2400/2666, 2*u-dimm, up to 32 gb |
|
storage |
3*sata 3.0, 1*sata 3.0/ msata |
|
expansion interface |
1*pcie x16, 1*pcie x4 or 1*pcie x2 1*pcie x1 1*mini-pcie (wifi/3g/4g supported), 4*pci |
|
bios |
ami uefi bios |
|
system |
windows 10, linux |
|
i/o interface |
|
|
ethernet |
2*intel® 1gbps pcie ethernet controller, rj45 |
|
serial |
4*rs232, 1*rs232/rs485, 1*rs232/rs485/rs422 |
|
usb |
4*usb 3.0, 5*usb 2.0 |
|
audio |
realtek® alc662 5.1 channel hda codec, with mic/line-out/line-in |
|
ps/2 |
1*ps/2 port (keyboard & mouse) |
|
gpio |
8*programmable gpio |
|
feature interface |
1*tpm, 1*case open header |
|
display |
|
|
display interface |
1*dvi-d: max resolution up to 1920x1200@60hz
1*hdmi 1.4b: max resolution up to 4096x2160@24hz
1*vga: max resolution up to 1920x1200@60hz |
|
multiple display |
dual |
|
mechanical & environment |
|
|
dimension |
305*244mm |
|
power input |
atx 28p |
| temperature |
operation: 0℃~60℃, storage: -25℃~75℃ |
|
relative humidity |
operation: 10%~90%, storage: 5%~95%, non-condensing |
