svx-12s23mp-h610
intel 12/13/14代i3/i5/i7/i9处理器, h610芯片, 2*lan, 1*type-c, 2*usb 3.2 gen 1, 6*usb 2.0, 2*m.2,支持三显
- 支持intel core 12/13/14代i3/i5/i7/i9 pentium/ celeron处理器
- 采用h610芯片组
- 支持ddr5内存, 最大96gb
- 2*千兆网口, 1*type-c, 2*usb 3.2 gen 1, 6*usb 2.0
- 1*sata 3.0, 1*mxm(pcie4.0 x16), 2*m.2
- 1*mini-hdmi, 1*lvds, 1*dp
规格
|
general |
|
|
cpu |
intel® coretm 12/13/14th gen alder lake-n processor |
|
chipset |
intel® h610 chipset, tdp 6w |
|
memory |
ddr5-5600, 2*so-dimm, up to 96gb |
|
storage |
1*sata 3.0 1*m.2(m-key 2242/2280, support pcie x4/sata ssd auto detect) |
|
expansion |
1*mxm(pcie4.0 x16) 1*m.2(key-e 2230, pcie x1 usb 2.0, wifi bluetooth with cnvi) |
|
bios |
ami uefi bios |
| os | windows 10/11 64bit, linux |
|
i/o |
|
|
ethernet |
2*realtek® gbe conroller, rj45 |
|
serial |
1*rs232 |
|
usb |
1*type-c, 2*usb 3.2 gen 1, 6*usb 2.0 |
|
audio |
realtek® hda codec, with line-out, mic and amplifier |
|
others |
1*ftpm2.0 |
|
display |
|
|
display interface |
1*mini-hdmi, 1*lvds, 1*dp |
|
multiple display |
triple |
|
mechanical & environment |
|
|
dimension |
180*180mm |
|
power input |
dc 19v |
| temperature |
operation: 0℃~60℃, storage: -25℃~75℃ |
|
relative humidity |
5%~95%, non-condensing |
