intel 6/7th gen core i3/i5/i7 cpu with h110, 6*usb 3.0, svio double-layer rear i/o design

supports intel 6/7th gen core i3/i5/i7 cpu with h110 chipset

6*usb 3.0, 4*usb 2.0, 6*com, 2*gbe lan

svio double-layer rear i/o design, up to 18*com, 18*usb when connects sv-m5 i/o module

supports dual display of vga and hdmi

1*pcie x16, 2*mini-pcie (1*msata, 1*wifi/3g/4g)

driver downloads

specifications

general
cpu	intel^® 6^th and 7^th generation core^tm i3/i5/i7, pentium^®, celeron^® cpu, lga1151
chipset	intel^®h110 chipset, tdp 6w
memory	ddr4-2133, 2*u-dimm, up to 32 gb
storage	2sata 3.0, 1msata
expansion interface	1pcie x16, 2mini-pcie (1msata, 1wifi/3g/4g supported)
bios	ami uefi bios
system	windows7/8.1/10, linux
i/o interface
ethernet	2*realtek^® 1gbps pcie ethernet controller, rj45
serial	6rs232 (up to 18rs232 with sv-m5-cu)
usb	6usb 3.0, 4usb 2.0 (up to 18*usb with sv-m5-cu)
audio	realtek^® alc662 5.1 channel hda codec, with mic/line-out
ps/2	1*ps/2 port (keyboard & mouse)
gpio	8*programmable gpio
display
display interface	1vga: max resolution up to 19201200@60hz 1hdmi: max resolution up to 40962160@24hz
multiple display	dual
mechanical & environment
dimension	170*170mm
power input	atx psu
temperature	operation: 0℃~60℃, storage: -25℃~75℃
relative humidity	operation: 10%~90%, storage: 5%~95%, non-condensing
