intel coffee lake 8th gen core i3/i5/i7 cpu with h310, 10*com, 12*usb, 2*lan, 1*pcie x16
|
general |
|
|
cpu |
intel® 8th and 9th generation core™ i3/i5/i7, pentium®, celeron® cpu, lga1151 |
|
chipset |
intel® h310, tdp 6w |
|
memory |
ddr4-2400, 2*u-dimm, up to 32 gb |
|
storage |
2*sata 3.0, 1*msata |
|
expansion interface |
1*pcie x16 2*mini-pcie (1*msata, 1*wifi/3g/4g supported) |
|
bios |
ami uefi bios |
|
system |
windows7/8/10, linux |
|
i/o interface |
|
|
ethernet |
2*realtek® 1gbps pcie ethernet controller, rj45 |
|
serial |
10*rs232 |
|
usb |
4*usb 3.0, 8*usb 2.0 |
|
audio |
realtek® 5.1 channel hda codec, with mic/line-out/line-in |
|
ps/2 |
1*ps/2 port (keyboard & mouse) |
|
gpio |
8*programmable gpio |
|
display |
|
|
display interface |
1*vga: max resolution up to 1920*1200@60hz 1*hdmi: max resolution up to 3840*2160@24hz |
|
multiple display |
dual |
|
mechanical & environment |
|
|
dimension |
170*170mm |
|
power input |
atx psu |
| temperature |
operation: 0℃~60℃, storage: -25℃~75℃ |
|
relative humidity |
operation: 10%~90%, storage: 5%~95%, non-condensing |
